Hyundai HY30100V 14CFM, 3HP, 100 Litre V Twin Direct Drive Air Compressor

The HY30100V is a powerful yet compact 3hp V-twin cylinder direct drive air compressor from Hyundai. Designed for DIY and trade applications the HY30100V air compressor is ideal for spray-painting, operating air tools in the workshop or home garage inflating tyres and inflatables.

Weighing 60kg the HY30100V features 2 rear wheels and transportation handle for easy maneuverability. The V-Twin pump features long lasting cast iron cylinders and aluminium cylinder heads for improved cooling, and comes ready to go including oil. (Replace the transit plug with the breather/filler plug before use).

Powered by a 3hp electric motor with a 230v 13amp plug, makes it ideal for home workshop or garage use where conventional residential power sockets are available.

The 5 piece tool kit, which comes with the compressor provides the essential tools to get you started straight out the box for a variety of tasks including spraying, blowing, degreasing and tyre inflating.

The V-twin direct drive design connects the motor straight to the pump increasing efficiency, allowing all the 3hp produced by the motor to be used to drive the compressor air pump producing more power in what is a very compact design.

The 100 litre tank capacity provides a constant supply of air for airtools with 14CFM, 396 litres per minute air displacement. Twin quick release air outlets for increased versatility allow two air-lines / tools to be connected at the same time. The pressure regulator allows the outlet pressure to be increased or decreased and the two pressure gauges measure pressure in the tank and the outlet pressure. It's also fitted with an over pressure safety valve, the automatic pressure control system switches the compressor off when the maximum pressure of 8 bar has been reached and restarts it when pressure drops to 6 bar.

Fitted with quick release Euro connectors this compressor is fitted with a standard 13A UK 3-pin Plug.

This air compressor provides a fantastic combination of performance and durability ideal for DIY and trade applications.

In the box: HY30100V Electric Air Compressor, 5-piece air tool kit (high pressure 2m coiled hose with male and female Q/R Euro fittings, tyre inflator, degreaser, spray gun and air duster/jetter all with Q/R fitting) and User Manual.

Assembly required: Fit wheels (2 bolts), fit cylinder head heat covers (4 screws), fit two rubber feet and screw in air filters. Compressor pump if filled with oil ready for use. This should take 10-15 minutes.

  • Powered by a Hyundai 2.2kW 3hp 230v motor.

  • V-twin direct drive pump fitted with a standard 13A UK Plug.

  • 100 litre tank capacity provides an air displacement of 14CFM or 396 litres per minute and 8bar / 116psi.

  • Fitted with twin Euro quick release connectors.

  • 5 piece tool kit including spray gun, air duster/jetter, degreaser gun, hose with Q/R fittings & tyre inflator.

  • Includes twin pressure gauges, automatic cut out switch, safety valve and pressure regulator/ adjuster.
Model HY30100V
Motor Power 2.2kW / 3hp
Voltage 230.00
Air Displacement 396L/Min
Discharge Pressure 8BAR / 116PSI
Tank Size 100L
Motor Speed 2850rpm
Air Outlet Euro Quick Release
Sound Rating 60dB
Dimensions L X W X H (mm) 1020X430X730
Net Weight 60.00

Brand: Hyundai

Identifier: HY30100V


Hyundai HY30100V 14CFM, 3HP, 100 Litre V Twin Direct Drive Air Compressor

1/5

A very frustrating experience!! During the basic customer assembly, I encountered a number of problems ..... 1. To enable the wheels to be assembled securely, without any play, I had to use my own washers as the ones provide were too thin. 2. One of the screws for attaching a cylinder cover was too long and could not be inserted due to obstruction by a pipe union. I had to provide a shorter one of my own. 3. Once assembled, the compressor was unbalanced as one of the anti-vibration feet was shorter than the other. I had to pack the rubber foot with some washers to level it out. 4. During the Test Run procedure, it states in the supplied handbook, that after pressurising the tank, at Step 4.16 it is required to release the air by pulling the safety valve. There is no ring pull or other means of doing this on the safety valve installed! I had to depressurise the tank via a tool attached to an outlet coupler. After Sitebox contacted Genpower, who are Hyundai power products importers, they were told Hyundai no longer fit the pull ring to the safety valve as customers were using it to depressurise the tank and causing it to wear! Even though they were told to do so!! Genpower did not respond to numerous emails regarding these issues. The warranty for the compressor is with Genpower. They respond to reviews on their website but they are totally unresponsive if there is a problem. Sitebox were prompt and efficient with their responses.

By on Wed 9th September 2020

Hyundai HY30100V 14CFM, 3HP, 100 Litre V Twin Direct Drive Air Compressor

5/5

Arrived quickly and was packed well , all works fine and it looks well made so pleased so far.

By on Tue 9th June 2020

Hyundai HY30100V 14CFM, 3HP, 100 Litre V Twin Direct Drive Air Compressor

5/5

Not used it yet but very impressed with quality and very well priced, packed very well.

By on Thu 28th May 2020
