449.99 2024-12-04360° green laser line projection for multi-directional alignment – perfect for large and bright environments. The laser’s vertical lines are easily adjusted once the plumb point (cross-section of two vertical lines), which is located outside the device, is set.
Ideal for bright environments and large work environments as green laser lines are up to four times more visible to the human eye if compared to red lasers.
Product Highlights
Features
Green Visibility
Easy Set-up and Positioning
Li-Ion Innovative
Self-leveling
Preferred Settings
Continuous Working
Rugged Design
Standard
Specification
Product | Leica Lino L6G 360° Green Laser |
Beam horizontal | 360° |
Beam vertical | 2 x 360° |
Intersection points | up, down, right, left, front, back (90° / 180°) |
Range / diameter* | 35 m / 70 m (115 ft / 230 ft) |
Range / diameter* with Leica RGR 200 receiver | 70 m / 140 m (230 ft / 460 ft) |
Levelling accuracy | ± 0.2 mm/m (± 0.002 in/ft) |
Horizontal- and Vertical line accuracy | ± 0.3 mm/m (± 0.004 in/ft) |
Intersection point accuracy | ± 0.2 mm/m (± 0.002 in/ft) |
Self-levelling range | ± 4° |
Self-levelling time | < 3 sec |
Fine adjustment | ± 10° around vertical intersection point |
Out-of-level warning | yes - blink lines every 5 s |
Levelling | pendulum (lockable) |
Laser | 525 nm / class 2 (acc. to IEC 60825-1) |
Protection class | IP54 (dust and splash water) |
Laser line intensity (selectable) | 100 %, 75 %, 50 % |
Operating time with Li-Ion | - |
Li-Lon | up to 11 h (3 beam, 50 % power) |
Operating time with Alkaline | - |
Alkaline | up to 8 h (3 beam, 50 % power) |
Dimensions | 124 x 107 x 154 mm (4.88 x 4.21 x 6.06 in) |
Weight | 781 g (1.71 lbs) |
Operation temperature | -10 to +50° C (14 to 122° F) |
Storage temperature | -25 to +70° C (-13 to +158° F) |
Laser line width @ 5 m (16.4 ft) distance | < 2 mm (< 0.08 in) |
Tripod thread | 1/4 in (5/8 in with adapter) |
Pulse power for receiver | yes |
